Trencher Digga Bigfoot Trenchers Excavation & Earthmoving Trencher

Bigfoot XD

Suit Machine Types:

Tele-Handlers, Truck Cranes, Front End Loaders, Wheeled Loaders, Back Hoes, Skid Steer Loaders. Up to 3.5 Tonne

Heavy Duty Bigfoot for machinery up to 3.5 Tonne. Fitted with a compact, yet powerful Quality Digga Planetary Drive system, this trenching attachment range ranks as the leading performer in the industry. An adjustable skid foot allows for constant trench depth control, with a single spoil auger for efficient removal of spoil to one side of the trench. Frame can be manually side shifted for digging close to permanent structures ie buildings, trees.

Bigfoot XD for heavy duty trenching up to 1200mm digging depth and 300mm digging width fitted with a 2” pitch chain with 4 selections of premium cutting systems to suit your individual needs.

Order Code	Description	Max Flow (LPM)	Max Pressure (BAR)
BFTXD2-32-900-CR	900 DIG - 150MM CUT EARTH WITH CRUMBER BAR	60-115	240
BFTXD2-32-1200 CR	1200 DIG - 200MM CUT EARTH WITH CRUMBER BAR	70-115	240

Xtra Drive to suit Digga Bigfoot

Xtra Drive is a attached to the motor to keep its speed nearly constant. Xtra drive stores energy to provide more power when needed. During Trenching debris within the ground can effect the driving forces from the hydraulics become momentarily less than is necessary to drive the trencher causing it to stall. The Extra Drives stored inertia keeps the speed from decreasing quickly. It is ideally used where the forces driving the Machine are not constant such as on lower flow machinery

Order Code	Description
T-XTRA	XTRA DRIVE

UNIVERSAL CRUMBER

This spring loaded crumber is available on all trenchers with varying plates to suit trench widths.

The crumbers have springs to give constant down pressure on the bottom of trench to scoop all spoil missed in the initial cut of the chain, throwing it back onto the chain to be carried back to the surface.

Please specify when selling or commissioning the trencher that the crumber must be in the fold back position until the trench has started, then drop the crumber forward and pin off to continue trenching.

If the crumber is in the trenching position from the top of the ground the spring in the trencher will over extend as it is going down the first part of the trench resulting in possible crumber failure and damage.

	Order Code	Description
TR-000600	CRUMBER BAR UNIVERSAL

Order Code

Description

TR-000600

CRUMBER BAR UNIVERSAL

CHAINS to suit Bigfoot XD Trencher

bigfoot chain

Bigfoot XD Trencher 900 MM DIG

EARTH 2" PITCH

Cup tooth on every second station of the chain. Only for soft clean grounds with no floater or tree roots.

Order Code	Chain Size	Description
TCB2-30-150-E	2 IN	900 DIG (30STN) - 150MM CUT EARTH
TCB2-30-200-E	2 IN	900 DIG (30STN) - 200MM CUT EARTH
TCB2-30-250-E	2 IN	900 DIG (30STN) - 250MM CUT EARTH
TCB2-30-300-E	2 IN	900 DIG (30STN) - 300MM CUT EARTH

FROST 2" PITCH

Cup tooth on every station of the chain. Better chain for clean ground with some tree root as this gives a chain saw effect and can saw through small roots. Will still buck and jump if in shale/rocky ground.

Order Code	Chain Size	Description
TCB2-30-150-F	2 IN	900 DIG (30STN) - 150MM CUT FROST
TCB2-30-200-F	2 IN	900 DIG (30STN) - 200MM CUT FROST
TCB2-30-250-F	2 IN	900 DIG (30STN) - 250MM CUT FROST
TCB2-30-300-F	2 IN	900 DIG (30STN) - 300MM CUT FROST

COMBO 2" PITCH

Combination of 70% Diggatac tooth, 30% Cup tooth. This combination gives an all round performance. Able to cut through soil, tree root, shale and rocky grounds. The combination allows for a cleaner trench in soil with the cup teeth bringing the soil to the surface.

Order Code	Chain Size	Description
TCB2-30-150-C	2 IN	900 DIG (30STN) - 150MM CUT COMBO
TCB2-30-200-C	2 IN	900 DIG (30STN) - 200MM CUT COMBO
TCB2-30-250-C	2 IN	900 DIG (30STN) - 250MM CUT COMBO
TCB2-30-300-C	2 IN	900 DIG (30STN) - 300MM CUT COMBO

DIGGATAC 2" PITCH

The most advanced Trencher cutting system in the World today. This chain will cut through all ground and is able to grind through the hardest of shale. Diggatac provides extended tooth life and reduced vibration particularly when starting in tough conditions.

Order Code	Chain Size	Description
TCB2-30-150-D	2 IN	900 DIG (30STN) - 150MM CUT DIGGATAC
TCB2-30-200-D	2 IN	900 DIG (30STN) - 200MM CUT DIGGATAC
TCB2-30-250-D	2 IN	900 DIG (30STN) - 250MM CUT DIGGATAC
TCB2-30-300-D	2 IN	900 DIG (30STN) - 300MM CUT DIGGATAC

Bigfoot XD Trencher 1200 MM DIG

EARTH 2" PITCH

Cup tooth on every second station of the chain. Only for soft clean grounds with no floater or tree roots.

Order Code	Chain Size	Description
TCB2-36-150-E	2 IN	1200 DIG (36STN) - 150MM CUT EARTH
TCB2-36-200-E	2 IN	1200 DIG (36STN) - 200MM CUT EARTH
TCB2-36-250-E	2 IN	1200 DIG (36STN) - 250MM CUT EARTH
TCB2-36-300-E	2 IN	1200 DIG (36STN) - 300MM CUT EARTH

FROST 2" PITCH

Order Code	Chain Size	Description
TCB2-36-150-F	2 IN	1200 DIG (36STN) - 150MM CUT FROST
TCB2-36-200-F	2 IN	1200 DIG (36STN) - 200MM CUT FROST
TCB2-36-250-F	2 IN	1200 DIG (36STN) - 250MM CUT FROST
TCB2-36-300-F	2 IN	1200 DIG (36STN) - 300MM CUT FROST

COMBO 2" PITCH

Order Code	Chain Size	Description
TCB2-36-150-C	2 IN	1200 DIG (36STN) - 150MM CUT COMBO
TCB2-36-200-C	2 IN	1200 DIG (36STN) - 200MM CUT COMBO
TCB2-36-250-C	2 IN	1200 DIG (36STN) - 250MM CUT COMBO
TCB2-36-300-C	2 IN	1200 DIG (36STN) - 300MM CUT COMBO

DIGGATAC 2" PITCH

Order Code	Chain Size	Description
TCB2-36-150-D	2 IN	1200 DIG (36STN) - 150MM CUT DIGGATAC
TCB2-36-200-D	2 IN	1200 DIG (36STN) - 200MM CUT DIGGATAC
TCB2-36-250-D	2 IN	1200 DIG (36STN) - 250MM CUT DIGGATAC
TCB2-36-300-D	2 IN	1200 DIG (36STN) - 300MM CUT DIGGATAC

SCRAPER SHOES

Order Code	Description
SS-000001	SCRAPER SHOE 6 IN - 140W X 370L X 8MM
SS-000002	SCRAPER SHOE 8 IN - 190W X 370L X 8MM
SS-000003	SCRAPER SHOE 10 IN - 240W X 370L X 8MM
SS-000004	SCRAPER SHOE 12 IN - 290W X 370L X 8MM
SS-000005	SCRAPER SHOE 14 IN - 340W X 370L X 8MM

TEETH

Order Code	Description
W-000097	CUP TOOTH - 2 IN - LEFT HAND (CH1)
W-000099	CUP TOOTH - 2 IN - RIGHT HAND (CH2)
2TDC	TOOTH - 2 IN CENTRE CUTTER DIGGATAC
2TDL	TOOTH - 2 IN LEFT HAND CUTTER DIGGATAC
2TDR	TOOTH - 2 IN RIGHT HAND CUTTER DIGGATAC

DRIVE SPROCKETS

Order Code	Description
TR-000060	DRIVE SPROCKET - SUIT 2 IN PITCH CHAIN - 11 TOOTH
TR-000045	AUGER SHAFT AND SPROCKET

NOSE ROLLER BEARING

Order Code	Description
BE-000017	BEARING - NOSE ROLLER W211 - PP5 - 2IN
TR-000871	NOSE ROLLER KIT - 2 IN - COMPLETE WITH BEARING & CIRCLIP
