Digga Profila

The Digga Profile Range is perfect for planing (mill) rock, concrete and asphalt

Standard Flow Features:

Digga Planetary drive delivers high torque
All purpose picks for use on both asphalt and concrete
Independant self-levelling depth adjustment plates which allow for precise lapping cuts and taper cuts
Manual depth and tilt options available
Convient ergonomic electro-hydraulic control joystick for depth, tilt and side shift (optional)
Water nozzle kit for dust supression supplied as standard (water tank not included)
Solid hardened steel wheels with greaseable manifold pins and secluded greased zerks
300mm standard drum
1 year limited warranty

High Flow Features:

2 models available HP450 and HP 600
Digga Planetary drive delivers high torque
High rear spoil clearance to prevent recirculation of material
Independant self-levelling depth adjustment plates which allow for precise lapping cuts and taper cuts
Manual depth and tilt options available
Convient ergonomic electro-hydraulic control joystick for depth, tilt and side shift (optional)
Water nozzle kit for dust supression supplied as standard (water tank not included)
Solid hardened steel wheels with greaseable manifold pins and secluded greased zerks
Exclusive angled spoil guard wheel design
1 year limited warranty

Ideal Use:

Specifications	SP300	HP450	HP600
Machine	Skid Steer Loaders	High Flow Skid Steer Loaders	High Flow Skid Steer Loaders
Weight (Kgs)	680	997	1088
Length (Overall)	1110	1277	1277
Width (Overall)	1320	1776	1776
Height (Overall)	816	878	878
Planing Width	305	457	610
Planing Depth	0 - 127mm	0 - 127 mm	0 - 127 mm
Drum Diameter	482	560	560
Number of picks (std drum)	37	45	57
Hydraulic Flow Required - LOW	NOT APPLICABLE	83 -106 LPM	83 - 106 LPM
Hydraulic Flow Required - STD	45 - 84 LPM	109 - 132 LPM	109 - 132 LPM
Hydraulic Flow Required - HIGH	NOT APPLICABLE	136 - 166 LPM	136 - 166 LPM
Operating Pressure (BAR)	170 - 240	170 - 240	170 - 240
HP Range - LOW FLOW	NOT APPLICABLE	36 - 48HP	36 - 48HP
HP Range - STD FLOW	25 - 33HP	48 - 58HP	48 - 58HP
HP Range - HIGH FLOW	NOT APPLICABLE	60 - 71HP	60 - 71HP
Tilt	11 degrees	8 degrees	8 degrees
Side Shift (centre to right)	0- 482mm	-75mm - 560mm	-75mm - 560mm
